HE4HNWPR Series

Catalog

EUROSTRIP 6P10MM STANDOFF 30A 60

Part	Voltage Rating	Pitch	Top Termination	Number of Circuits	Barrier Type	Terminal Block Type	Wire Gauge (AWG) (Max)	Wire Gauge (AWG) (Min)	Number of Wire Entries	Bottom Termination	Color	Number of Rows	Current Rating	Mounting Type	Terminal Screw Finish	Material - Insulation	Operating Temperature (Min)	Operating Temperature (Max)	Material Flammability Rating	Terminal Screw Material
Altech Corporation HE4HNWPR/06	600 V	0.394 in	Screws	6	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	12	Closed	White	2	30 A
Altech Corporation HE4HNWPR/09	600 V	0.394 in	Screws	9	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	18	Closed	White	2	30 A
Altech Corporation HE4HNWPR/04	600 V	0.394 in	Screws	4	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	8	Closed	White	2	30 A
Altech Corporation HE4HNWPR/07	600 V	0.394 in	Screws	7	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	14	Closed	White	2	30 A
Altech Corporation HE4HNWPR/08	600 V	0.394 in	Screws	8	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	16	Closed	White	2	30 A
Altech Corporation HE4HNWPR/12	600 V	0.394 in	Screws	12	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	24	Closed	White	2	30 A	Chassis Panel	Blue Chromate	Nylon 6/6 PA66 Polyamide	-30 °C	125 °C	UL94 V-0	Steel
Altech Corporation HE4HNWPR/10	600 V	0.394 in	Screws	10	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	20	Closed	White	2	30 A
Altech Corporation HE4HNWPR/11	600 V	0.394 in	Screws	11	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	22	Closed	White	2	30 A
Altech Corporation HE4HNWPR/02	600 V	0.394 in	Screws	2	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	4	Closed	White	2	30 A
Altech Corporation HE4HNWPR/05	600 V	0.394 in	Screws	5	Enclosed	Eurostyle Terminal Strip	24 AWG	10 AWG	10	Closed	White	2	30 A
