SRR6038 Series
Manufacturer: Bourns Inc.
Beta
⌘K
FIXED IND 12UH 1.7A 53 MOHM SMD
| Part | Operating Temperature [Max] | Operating Temperature [Min] | DC Resistance (DCR) [Max] | Current Rating (Amps) | Frequency - Self Resonant | Tolerance | Height - Seated (Max) | Height - Seated (Max) [Max] | Inductance Frequency - Test | Material - Core | Mounting Type | Shielding | Current - Saturation (Isat) | Package / Case | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Type | Inductance | Q @ Freq | Q @ Freq [custom] | Q @ Freq [custom] | DC Resistance (DCR) | Q @ Freq [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 125 °C | -40 C | 53 mOhm | 1.7 A | 17.9 MHz | 30 % | 4 mm | 0.157 in | 100 kHz | Ferrite | Surface Mount | Shielded | 1.95 A | Nonstandard | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Drum Core Wirewound | 12 µH | 2.52 MHz 8.3 | ||||
Bourns Inc. | 125 °C | -40 C | 34 mOhm | 2.2 A | 27.5 MHz | 30 % | 4 mm | 0.157 in | 100 kHz | Ferrite | Surface Mount | Shielded | 2.35 A | Nonstandard | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Drum Core Wirewound | 8.7 µH | 7.96 MHz | 7.3 | |||
Bourns Inc. | 125 °C | -40 C | 2 A | 24.9 MHz | 30 % | 4 mm | 0.157 in | 100 kHz | Ferrite | Surface Mount | Shielded | 2.05 A | Nonstandard | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Drum Core Wirewound | 10 µH | 2.52 MHz 8.8 | 38 mOhm | ||||
Bourns Inc. | 125 °C | -40 C | 57 mOhm | 1.6 A | 18 MHz | 30 % | 4 mm | 0.157 in | 100 kHz | Ferrite | Surface Mount | Shielded | 1.9 A | Nonstandard | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Drum Core Wirewound | 15 µH | 8.6 | 2.52 MHz | |||
 Bourns Inc. | 125 °C | -40 C | 138 mOhm | 1 A | 11.8 MHz | 30 % | 4 mm | 0.157 in | 100 kHz | Ferrite | Surface Mount | Shielded | 1.1 A | Nonstandard | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Drum Core Wirewound | 39 µH | 2.52 MHz 8.3 |
