L829 Series
Modular Connectors / Ethernet Connectors MagJack 1000BaseT, 1X1, Y/G, Tab Up, Low Profile, RoHS
Manufacturer: Bel Fuse Inc.
Catalog
Modular Connectors / Ethernet Connectors MagJack 1000BaseT, 1X1, Y/G, Tab Up, Low Profile, RoHS
Beta
⌘K
Modular Connectors / Ethernet Connectors MagJack 1000BaseT, 1X1, Y/G, Tab Up, Low Profile, RoHS
Modular Connectors / Ethernet Connectors MagJack 1000BaseT, 1X1, Y/G, Tab Up, Low Profile, RoHS
Modular Connectors / Ethernet Connectors MagJack 1000BaseT, 1X1, Y/G, Tab Up, Low Profile, RoHS
| Part | Mounting Type | Number of Cores per Jack | Shielding | Termination | Tab Direction | Connector Type | LED Color | Features | Applications | Number of Rows | Contact Finish | Number of Ports | Orientation | Height Above Board | Height Above Board | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Shield Material | Housing Material | Contact Finish Thickness | Contact Finish Thickness | Height Above Board |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | Through Hole | 8 | EMI Finger Shielded | Solder | Up | RJ45 | Yellow - Green | Board Guide Light Pipe | 1G Base-T AutoMDIX | 1 | Gold | 1 | 90 ° | 0.445 in | 11.3 mm | ||||||||
 Bel Fuse Inc. | Through Hole | EMI Finger Shielded | Solder | Up | RJ45 | Green Orange Yellow | Board Guide | 10/100 Base-T AutoMDIX | 1 | Gold | 1 | 90 ° | 0.445 in | 11.3 mm | 70 °C | 0 °C | Copper Alloy | ||||||
 Bel Fuse Inc. | Through Hole | 8 | EMI Finger Shielded | Solder | Up | RJ45 | Green - Green | Board Guide | 10/100/1000 Base-T AutoMDIX | 1 | Gold | 1 | 90 ° | 0.445 in | 11.3 mm | 70 °C | 0 °C | Copper Alloy | |||||
 Bel Fuse Inc. | Board Edge Through Hole | EMI Finger Shielded | Solder | Up | RJ45 | Orange Yellow - Green | Board Guide | 2.5G Base-T AutoMDIX | 1 | Gold | 1 | 90 ° | 0.44 in | 70 °C | 0 °C | Copper Alloy | Polyamide (PA) Nylon | 30 Áin | 0.76 Ám | 11.18 mm |
