WS0850100 Series
Manufacturer: E-Switch
Beta
⌘K
SWITCH SNAP ACTION SPDT 1A 24V
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating - DC | Mounting Type | Switch Function | Current Rating (Amps) | Mechanical Life | Circuit | Actuator Type | Termination Style | Operating Force | Ingress Protection | Operating Position | Operating Position | Electrical Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | 85 °C | -25 °C | 24 V | Chassis Mount | On-Mom | 1 A | 1000000 Cycles | SPDT | Round (Pin Plunger) | Wire Leads | 70 gf | IP67 - Dust Tight Waterproof | 0.413 in | 10.5 mm | 10000 Cycles |
