CI0102P1 Series
Manufacturer: Cvilux USA
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
2 POS 2.00MM(.079) SINGLE ROW ST
| Part | Contact Length - Post | Style | Shrouding | Mounting Type | Contact Type | Connector Type | Fastening Type | Insulation Material | Number of Positions | Contact Material | Insulation Color | Material Flammability Rating | Voltage Rating | Voltage Rating (Type) | Pitch - Mating | Contact Shape | Contact Finish - Post | Termination | Insulation Height | Number of Rows | Contact Finish Thickness - Mating | Contact Finish - Mating | Operating Temperature (Max) | Operating Temperature (Min) | Current Rating | Number of Positions Loaded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 0.134 in | Board Cable/Wire | Shrouded - 4 Wall | Through Hole | Male Pin | Header | Detent Lock | Nylon 6/6 Polyamide (PA66) | 2 | Brass | Natural | UL94 V-0 | 250 V | DC | 0.079 in | Square | Tin | Kinked Pin Solder | 0.24 in | 1 | 120 µin | Tin | 105 °C | -25 °C | 2 A | All |
