1672A Series
Manufacturer: Belden Inc.
Beta
⌘K
#29 TFE SH TINNED COAX
| Part | Conductor Material | Dielectric Material | Shield Material | Operating Temperature [Min] | Operating Temperature [Max] | Shield Coverage | Dielectric Diameter [diameter] | Dielectric Diameter [diameter] | Impedance | Shield Type | Cable Type | Length [x] | Length [x] | Conductor Strand | Wire Gauge | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Copper Covered Silver Coated Steel | Tetrafluoroethylene (TFE) | Copper Bare Tin | -70 °C | 200 °C | 100 % | 1.57 mm | 0.062 in | 75 Ohms | Braid Foil | Coaxial | 152.4 m | 500 ft | Solid | 29 AWG | 2.21 mm | 0.087 in |
Belden Inc. | Copper Covered Silver Coated Steel | Tetrafluoroethylene (TFE) | Copper Bare Tin | -70 °C | 200 °C | 100 % | 1.57 mm | 0.062 in | 75 Ohms | Braid Foil | Coaxial | 304.8 m | 1000 ft | Solid | 29 AWG | 2.21 mm | 0.087 in |
