R22290 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMP / STRAIGHT PLUG FULL CRIMP T
| Part | Voltage Rating | Body Finish | Center Contact Plating | Body Material | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Shield Termination | Contact Termination | Number of Ports | Fastening Type | Frequency - Max [Max] | Impedance | Cable Group | Cable Group | Connector Type | Mounting Type | Housing Color | Center Contact Material | Insertion Loss | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | 250 V | Gold | Gold | Brass | Polytetrafluoroethylene (PTFE) | -55 C | 125 °C | Crimp | Crimp | 1 | Snap-On | 12.4 GHz | 50 Ohms | 196 | RG-178 | Female Socket Plug | Free Hanging (In-Line) | Gold | Beryllium Copper | ||
 Radiall USA, Inc. | 335 V | Gold | Gold | Brass | Polytetrafluoroethylene (PTFE) | -55 C | 125 °C | Crimp | Crimp | 1 | Snap-On | 12.4 GHz | 50 Ohms | 316 | RG-174 | Female Socket Plug | Free Hanging (In-Line) Right Angle | Gold | Beryllium Copper | ||
 Radiall USA, Inc. | 250 V | Gold | Gold | Brass | Polytetrafluoroethylene (PTFE) | -55 C | 125 °C | Crimp | Crimp | 1 | Snap-On | 12.4 GHz | 50 Ohms | 188 316 RG-174 | Female Socket Plug | Free Hanging (In-Line) | Gold | Beryllium Copper | |||
Radiall USA, Inc. | 250 V | Brass | Polytetrafluoroethylene (PTFE) | -55 C | 125 °C | Crimp | Crimp | 1 | Snap-On | 12.4 GHz | 50 Ohms | RD-316 | Female Socket Jack | Free Hanging (In-Line) | Beryllium Copper | 0.12 dB | |||||
 Radiall USA, Inc. | 335 V | Gold | Gold | Brass | Polytetrafluoroethylene (PTFE) | -55 C | 125 °C | Crimp | Crimp | 1 | Snap-On | 12.4 GHz | 50 Ohms | 196 | RG-178 | Female Socket Plug | Free Hanging (In-Line) Right Angle | Gold | Beryllium Copper | ||
 Radiall USA, Inc. | 250 V | Gold | Gold | Brass | Polytetrafluoroethylene (PTFE) | -55 C | 105 ░C | Solder | Solder | 1 | Snap-On | 12.4 GHz | 50 Ohms | RG-405 (.085" Semi Rigid) | Female Socket Plug | Free Hanging (In-Line) Right Angle | Gold | Beryllium Copper | |||
 Radiall USA, Inc. | 335 V | Gold | Gold | Brass | Polytetrafluoroethylene (PTFE) | -55 C | 105 ░C | Solder | Solder | 1 | Snap-On | 12.4 GHz | 50 Ohms | RG-405 (.085" Semi Rigid) | Female Socket Plug | Free Hanging (In-Line) | Gold | Beryllium Copper | |||
Radiall USA, Inc. | 250 V | Gold | Gold | Brass | Polytetrafluoroethylene (PTFE) | -55 C | 105 ░C | Solder | Solder | 1 | Snap-On | 12.4 GHz | 50 Ohms | RG-405 (.085" Semi Rigid) | Female Socket Plug | Free Hanging (In-Line) Right Angle | Gold | Beryllium Copper | |||
 Radiall USA, Inc. | 250 V | Gold | Gold | Brass | Polytetrafluoroethylene (PTFE) | -55 C | 125 °C | Crimp | Crimp | 1 | Snap-On | 12.4 GHz | 50 Ohms | 196 | RG-178 | Female Socket Plug | Free Hanging (In-Line) | Gold | Beryllium Copper | ||
Radiall USA, Inc. | 250 V | White Bronze | Gold | Bronze | Polytetrafluoroethylene (PTFE) | -55 C | 125 °C | Crimp | Crimp | 1 | Snap-On | 12.4 GHz | 50 Ohms | TCE2H2 | Female Socket Plug | Free Hanging (In-Line) Right Angle | Silver | Beryllium Copper | Non-Magnetic |
