8P1P014 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CIRCULAR CONNECTOR, QUIK-LOQ 8P1P SERIES, RIGHT ANGLE BULKHEAD RECEPTACLE, 14 CONTACTS
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Connector Type | Ingress Protection | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shielding | Termination | Primary Material | Fastening Type | Color | Voltage Rating | Current Rating (Amps) | Orientation | Number of Positions | Mounting Feature | Shell Material | Mounting Type | Contact Finish - Mating | Insert Material | Contact Material | Features | Cable Opening [Max] | Cable Opening [Min] | Cable Opening [Min] | Cable Opening [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 120 °C | -20 ░C | Receptacle Female Sockets | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Solder | Plastic | Push-Pull | Gray | 333 V | 3 A | Keyed | 14 | Bulkhead - Front Side Nut | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Panel Mount Right Angle Through Hole | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | |||||
 NorComp Inc. | 120 °C | -20 ░C | Plug Male Pins | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Plastic | Push-Pull | 333 V | 3 A | Keyed | 14 | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Free Hanging (In-Line) | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | Backshell Strain Relief | 0.197 in | 4 mm | 0.157 in | 5 mm | |||
 NorComp Inc. | 120 °C | -20 ░C | Plug Male Pins | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Plastic | Push-Pull | Gray Green | 333 V | 3 A | Keyed | 14 | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Free Hanging (In-Line) | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | Backshell Strain Relief | 0.236 in | 5 mm | 0.197 in | 6 mm | ||
 NorComp Inc. | 120 °C | -20 ░C | Plug Male Pins | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Plastic | Push-Pull | Gray Yellow | 333 V | 3 A | Keyed | 14 | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Free Hanging (In-Line) | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.197 in | 4 mm | 0.157 in | 5 mm | |||
 NorComp Inc. | 120 °C | -20 ░C | Plug Male Pins | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Plastic | Push-Pull | Gray Green | 333 V | 3 A | Keyed | 14 | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Free Hanging (In-Line) | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.236 in | 5 mm | 0.197 in | 6 mm | |||
 NorComp Inc. | 120 °C | -20 ░C | Receptacle Female Sockets | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Plastic | Push-Pull | Gray Red | 333 V | 3 A | Keyed | 14 | Bulkhead - Front Side Nut | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Panel Mount | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | ||||||
NorComp Inc. | 120 °C | -20 ░C | Plug Male Pins | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Plastic | Push-Pull | Gray Red | 333 V | 3 A | Keyed | 14 | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Free Hanging (In-Line) | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | Backshell Strain Relief | 0.236 in | 5 mm | 0.197 in | 6 mm | ||
 NorComp Inc. | 120 °C | -20 ░C | Receptacle Female Sockets | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Solder | Plastic | Push-Pull | Gray Yellow | 333 V | 3 A | Keyed | 14 | Bulkhead - Front Side Nut | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Panel Mount Right Angle Through Hole | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | |||||
 NorComp Inc. | 120 °C | -20 ░C | Receptacle Female Sockets | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Solder | Plastic | Push-Pull | Blue Gray | 333 V | 3 A | Keyed | 14 | Bulkhead - Front Side Nut | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Panel Mount Right Angle Through Hole | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | |||||
 NorComp Inc. | 120 °C | -20 ░C | Plug Male Pins | IP50 - Dust Protected | 7 µin | 0.178 µm | Unshielded | Plastic | Push-Pull | Gray | 333 V | 3 A | Keyed | 14 | Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC) | Free Hanging (In-Line) | Gold | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.236 in | 5 mm | 0.197 in | 6 mm |
