1546833 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN BARRIER STRIP 5CIRC 0.375"
| Part | Operating Temperature | Top Termination | Number of Circuits | Terminal Block Type | Wire Gauge [Min] | Wire Gauge [Max] | Color | Features | Current Rating (Amps) | Terminal Screw Material | Pitch [x] | Pitch [x] | Terminal Screw Finish | Voltage Rating | Barrier Type | Material - Insulation | Material Flammability Rating | Number of Rows | Number of Wire Entries | Bottom Termination | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | 120 °C | Screws with Captive Plate | 5 | Barrier Block | 14 AWG | 22 AWG | Black | Cover | 15 A | Steel | 9.53 mm | 0.375 in | Nickel | 300 VDC | 3 Wall (Tri) | Nylon Polyamide (PA) | UL94 V-0 | 1 | 5 | PC Pin | Through Hole |
 TE Connectivity Raychem Cable Protection | 120 °C | Screws with Captive Plate | 4 | Barrier Block | 14 AWG | 22 AWG | Black | Cover | 15 A | Steel | 9.53 mm | 0.375 in | Nickel | 300 VDC | 3 Wall (Tri) | Nylon Polyamide (PA) | UL94 V-0 | 1 | 4 | PC Pin | Through Hole |
 TE Connectivity Raychem Cable Protection | 120 °C | Screws with Captive Plate | 3 | Barrier Block | 14 AWG | 22 AWG | Black | Cover | 15 A | Steel | 9.53 mm | 0.375 in | Nickel | 300 VDC | 3 Wall (Tri) | Nylon Polyamide (PA) | UL94 V-0 | 1 | 3 | PC Pin | Through Hole |
TE Connectivity Raychem Cable Protection | 120 °C | Screws with Captive Plate | 6 | Barrier Block | 14 AWG | 22 AWG | Black | Cover | 15 A | Steel | 9.53 mm | 0.375 in | Nickel | 300 VDC | 3 Wall (Tri) | Nylon Polyamide (PA) | UL94 V-0 | 1 | 6 | PC Pin | Through Hole |
