GEC08D Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
BOARD CONNECTOR, 16 CONTACT(S), 2 ROW(S), MALE, STRAIGHT, 0.1 INCH PITCH, SURFACE MOUNT TERMINAL
| Part | Material Flammability Rating | Number of Rows | Pitch - Mating | Pitch - Mating | Number of Positions | Contact Length - Mating [x] | Contact Length - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Shape | Insulation Color | Mounting Type | Connector Type | Insulation Material | Termination | Contact Finish - Post | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Height | Insulation Height | Style | Fastening Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Shrouding | Current Rating (Amps) | Contact Type | Number of Positions Loaded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | UL94 V-0 | 2 | 0.1 in | 2.54 mm | 16 | 0.23 in | 5.84 mm | 2.54 çm | 100 çin | Square | Black | Surface Mount | Breakaway Header | Nylon 9T Polyamide (PA9T) | Solder | Tin | 2.54 µm | 100 µin | 0.1 in | 2.54 mm | Board to Board Cable | Push-Pull | -65 ░C | 150 °C | Phosphor Bronze | 2.54 mm | 0.1 in | Unshrouded | 3 A | Male Pin | All |
