DEM09 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN D-SUB PLUG 9POS R/A SOLDER
| Part | Flange Feature | Number of Positions | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Connector Type | Material Flammability Rating | Shell Material, Finish | Termination | Contact Material | Dielectric Material | Number of Rows | Mounting Type | Backset Spacing | Backset Spacing | Contact Type | Voltage Rating | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Connector Style | Features | Ingress Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Male Pins Plug | UL94 V-0 | Steel Yellow Cadmium Plated | Solder | Phosphor Bronze | Thermoplastic | 2 | Through Hole Right Angle | 0.406 in | 10.3 mm | Signal | 300 VDC | 7.5 A | 155 °C | -55 °C | Gold | D-Sub | ||
Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Male Pins Plug | UL94 V-0 | Steel Yellow Cadmium Plated | Solder | Brass | Thermoplastic | 2 | Through Hole Right Angle | 0.406 in | 10.3 mm | Signal | 300 VDC | 7.5 A | 125 °C | -55 °C | Gold | D-Sub | Mounting Brackets | |
 Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Receptacle Female Sockets | UL94 V-0 | Steel Yellow Cadmium Plated | Solder | Phosphor Bronze | Thermoplastic | 2 | Through Hole | Signal | 300 VDC | 7.5 A | 155 °C | -55 °C | Gold | D-Sub | ||||
Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Receptacle Female Sockets | UL94 V-0 | Steel Yellow Cadmium Plated | Wire Wrap | Brass | Thermoplastic | 2 | Panel Mount Through Hole | Signal | 300 VDC | 7.5 A | 155 °C | -55 °C | Gold | D-Sub | ||||
 Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Male Pins Plug | UL94 V-0 | Steel Yellow Cadmium Plated | Solder | Thermoplastic | 2 | Through Hole Right Angle | 0.318 " | 8.08 mm | Signal | 300 VDC | 7.5 A | 155 °C | -55 °C | Gold | D-Sub | |||
 Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Male Pins Plug | UL94 V-0 | Steel Yellow Cadmium Plated | Solder | Brass | Thermoplastic | 2 | Through Hole | Signal | 300 VDC | 7.5 A | 125 °C | -55 °C | Gold | D-Sub | ||||
Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Receptacle Female Sockets | UL94 V-0 | Steel Yellow Cadmium Plated | Solder | Phosphor Bronze | Thermoplastic | 2 | Through Hole | Signal | 300 VDC | 7.5 A | 125 °C | -55 °C | Gold | D-Sub | Harsh Environment | |||
Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Male Pins Plug | UL94 V-0 | Steel Yellow Cadmium Plated | Wire Wrap | Brass | Thermoplastic | 2 | Panel Mount Through Hole | Signal | 300 VDC | 7.5 A | 125 °C | -55 °C | Gold | D-Sub | ||||
Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Male Pins Plug | UL94 V-0 | Steel Yellow Cadmium Plated | Solder | Phosphor Bronze | Thermoplastic | 2 | Through Hole Right Angle | 0.406 in | 10.3 mm | Signal | 300 VDC | 7.5 A | 155 °C | -55 °C | Gold | D-Sub | ||
 Amphenol ICC (FCI) | Housing/Shell (Unthreaded) | 9 | DE E | 1 | Receptacle Female Sockets | UL94 V-0 | Steel Yellow Cadmium Plated | Solder | Phosphor Bronze | Thermoplastic | 2 | Through Hole Right Angle | 0.406 in | 10.3 mm | Signal | 300 VDC | 7.5 A | 155 °C | -55 °C | Gold | D-Sub |
