CRHP Series
Manufacturer: Vishay Dale
Beta
⌘K
10M, 1%, 100PPMM, LEAD-FREE
| Part | Power (Watts) | Temperature Coefficient | Resistance | Height - Seated (Max) | Number of Terminations | Features | Tolerance | Package / Case | Package Name | Operating Temperature (Max) | Operating Temperature (Min) | Size / Dimension Width | Size / Dimension Length | Composition | Power (Watts) Options |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay Dale | 1 W | 100 ppm/°C | 10 MOhm | 0.027 in | 2 | High Voltage Moisture Resistant | 1 % | 2010 (5025 Metric) | 2010 | 155 °C | -55 °C | 0.1 in | 0.2 in | Thick Film | |
 Vishay Dale | 1.5 W | 100 ppm/°C | 100 MOhm | 0.027 in | 2 | High Voltage Moisture Resistant | 1 % | 2512 (6332 Metric) 2512 (6432 Metric) | 2512 | 155 °C | -55 °C | 0.126 in | 0.25 in | Thick Film | |
 Vishay Dale | 500 mW | 100 ppm/°C | 2 MOhm | 0.027 in | 2 | High Voltage Moisture Resistant | 1 % | 1206 (3216 Metric) | 1206 | 155 °C | -55 °C | 0.063 in | 0.125 in | Thick Film | 1/2W |
