SG137 Series

Catalog

IC REG LINEAR NEG ADJ 1.5A TO3

Part	Voltage - Output (Min/Fixed)	Package / Case	Current - Output	Grade	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output (Max) [Max]	Number of Regulators	Mounting Type	Qualification	Protection Features	Output Type	PSRR [Max]	PSRR [Min]	Output Configuration	Voltage - Input (Max) [Max]	Supplier Device Package
Microsemi Corporation SG137K	-1.25 V	TO-204AA TO-3	1.5 A	Military	-55 C	125 °C	-36 V	1	Through Hole	MIL-STD-883	Over Current Over Temperature Over Voltage	Adjustable	77 dB	60 dB	Negative	-36 V	TO-3
Microsemi Corporation SG137AIG-883B	-1.25 V	TO-257-3	1.5 A	Military	-55 C	125 °C	-36 V	1	Through Hole	MIL-STD-883	Over Current Over Temperature Over Voltage	Adjustable	80 dB	66 dB	Negative	-36 V	TO-257
