001088 Series

Manufacturer: Molex

Catalog

CONN HEADER VERT 56POS 2.54MM

Part	Fastening Type	Insulation Color	Insulation Height [z]	Insulation Height [z]	Contact Type	Termination	Mounting Type	Insulation Material	Shrouding	Connector Type	Style	Material Flammability Rating	Contact Shape	Number of Positions Loaded	Number of Rows [custom]	Contact Length - Mating [x]	Contact Length - Mating [x]	Pitch - Mating	Pitch - Mating	Overall Contact Length	Overall Contact Length	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Positions	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post	Contact Length - Post	Contact Material	Contact Finish - Post	Applications	Insulation Height	Insulation Height	Contact Length - Post [custom]
Molex 10-88-1561	Push-Pull	Black	0.09 in	2.29 mm	Male Pin	Solder	Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm	11.1 mm	0.437 in	0.1 in	2.54 mm	56	150 Áin	3.81 Ám	0.107 in	2.71 mm	Phosphor Bronze	Tin	Automotive General Purpose Lighting Medical Telecommunications
Molex 0010883121	Push-Pull	Black			Male Pin	Solder	Right Angle Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm			0.1 in	2.54 mm	12	150 Áin	3.81 Ám		2.79 mm	Copper Alloy	Tin	Automotive General Purpose Lighting Medical Telecommunications	5.6 mm	0.22 in	0.11 in
Molex 10-88-1061	Push-Pull	Black	0.09 in	2.29 mm	Male Pin	Solder	Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm	11.1 mm	0.437 in	0.1 in	2.54 mm	6	150 Áin	3.81 Ám	0.107 in	2.71 mm	Phosphor Bronze	Tin	Automotive General Purpose Lighting Medical Telecommunications
Molex 10-88-1505	Push-Pull	Black	0.2 in	5.08 mm	Male Pin	Solder	Right Angle Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm			0.1 in	2.54 mm	50	150 Áin	3.81 Ám		2.79 mm	Phosphor Bronze	Tin	Automotive General Purpose Lighting Medical Telecommunications			0.11 in
Molex 10-88-1181	Push-Pull	Black	0.09 in	2.29 mm	Male Pin	Solder	Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm	11.1 mm	0.437 in	0.1 in	2.54 mm	18	150 Áin	3.81 Ám	0.107 in	2.71 mm	Phosphor Bronze	Tin	Automotive General Purpose Lighting Medical Telecommunications
Molex 10-88-1101	Push-Pull	Black	0.09 in	2.29 mm	Male Pin	Solder	Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm	11.1 mm	0.437 in	0.1 in	2.54 mm	10	150 Áin	3.81 Ám	0.107 in	2.71 mm	Phosphor Bronze	Tin	Automotive General Purpose Lighting Medical Telecommunications
Molex 10-88-1321	Push-Pull	Black	0.09 in	2.29 mm	Male Pin	Solder	Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm	11.1 mm	0.437 in	0.1 in	2.54 mm		150 Áin	3.81 Ám	0.107 in	2.71 mm	Phosphor Bronze	Tin	Automotive General Purpose Lighting Medical Telecommunications
Molex 10-88-1621	Push-Pull	Black	0.09 in	2.29 mm	Male Pin	Solder	Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm	11.1 mm	0.437 in	0.1 in	2.54 mm	62	150 Áin	3.81 Ám	0.107 in	2.71 mm	Phosphor Bronze	Tin	Automotive General Purpose Lighting Medical Telecommunications
Molex 10-88-1781	Push-Pull	Black	0.09 in	2.29 mm	Male Pin	Solder	Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm	11.1 mm	0.437 in	0.1 in	2.54 mm	78	150 Áin	3.81 Ám	0.107 in	2.71 mm	Phosphor Bronze	Tin	Automotive General Purpose Lighting Medical Telecommunications
Molex 10-88-1481	Push-Pull	Black	0.09 in	2.29 mm	Male Pin	Solder	Through Hole	Polyester Glass Filled	Unshrouded	Header Breakaway	Board to Board Cable	UL94 V-0	Square	All	2	0.24 in	6.1 mm	0.1 "	2.54 mm	11.1 mm	0.437 in	0.1 in	2.54 mm	48	150 Áin	3.81 Ám	0.107 in	2.71 mm	Phosphor Bronze	Tin	Automotive General Purpose Lighting Medical Telecommunications
