68024 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN HEADER VERT 36POS 2.54MM
| Part | Voltage Rating | Connector Type | Number of Rows | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Number of Positions | Current Rating (Amps) | Contact Type | Number of Positions Loaded | Termination | Contact Length - Mating [x] | Contact Length - Mating [x] | Contact Finish - Mating | Pitch - Mating | Pitch - Mating | Overall Contact Length | Overall Contact Length | Contact Material | Mounting Type | Shrouding | Contact Length - Post [x] | Contact Length - Post [x] | Contact Shape | Insulation Color | Material Flammability Rating | Fastening Type | Insulation Height | Insulation Height | Contact Finish - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | 110 VDC | Header | 1 | 30 Áin | 0.76 Ám | 36 | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | Gold or Gold GXT™ | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm | |
Amphenol ICC (FCI) | 110 VDC | Header | 1 | 15 µin | 0.38 µm | 28 | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | Gold or Gold GXT™ | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm | |
Amphenol ICC (FCI) | 110 VDC | Header | 1 | 15 µin | 0.38 µm | 19 | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | Gold or Gold GXT™ | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm | |
Amphenol ICC (FCI) | 110 VDC | Header | 1 | 100 çin | 2.54 çm | 11 | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm | Tin | |
Amphenol ICC (FCI) | 110 VDC | Header | 1 | 15 µin | 0.38 µm | 12 | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | Gold or Gold GXT™ | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm | |
Amphenol ICC (FCI) | 110 VDC | Header | 1 | 30 Áin | 0.76 Ám | 7 | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | Gold or Gold GXT™ | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm | |
Amphenol ICC (FCI) | 110 VDC | Header | 1 | 100 çin | 2.54 çm | 18 | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm | Tin | |
Amphenol ICC (FCI) | 110 VDC | Header | 1 | 30 Áin | 0.76 Ám | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | Gold or Gold GXT™ | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm | ||
Amphenol ICC (FCI) | 110 VDC | Header | 1 | 100 çin | 2.54 çm | 30 | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm | Tin | |
Amphenol ICC (FCI) | 110 VDC | Header | 1 | 30 Áin | 0.76 Ám | 15 | 5 A | Male Pin | All | Solder | 0.318 " | 8.08 mm | Gold or Gold GXT™ | 0.1 in | 2.54 mm | 14.43 mm | 0.568 in | Phosphor Bronze | Through Hole | Unshrouded | 0.15 in | 3.81 mm | Square | Black | UL94 V-0 | Push-Pull | 0.1 in | 2.54 mm |
