9305 Series

Catalog

MULTI-PAIR 8COND 22AWG

Part	Shield Material	Shield Coverage	Conductor Strand	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Cable Type	Jacket (Insulation) Material	Voltage	Conductor Material	Usage	Conductor Insulation	Length	Length	Jacket Color	Features	Wire Gauge	Number of Conductors	Operating Temperature [Max]	Operating Temperature [Min]	Shield Type	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Ratings	Length [x]	Length [x]
Belden Inc. 9305 0601000	Aluminum	100 %	Solid	6.73 mm	0.265 in	Multi-Pair	Poly-Vinyl Chloride (PVC)	300 VDC	Copper Tinned	Audio Control Instrumentation	Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	Chrome	Drain Wire	22 AWG	8	80 °C	-20 ░C	Foil	0.813 mm	0.032 in
Belden Inc. 9305 0605000	Aluminum	100 %	Solid	6.73 mm	0.265 in	Multi-Pair	Poly-Vinyl Chloride (PVC)	300 VDC	Copper Tinned	Audio Control Instrumentation	Poly-Vinyl Chloride (PVC)			Chrome	Drain Wire	22 AWG	8	80 °C	-20 ░C	Foil	0.813 mm	0.032 in
Belden Inc. 9305 060100	Aluminum	100 %	Solid	6.73 mm	0.265 in	Multi-Pair	Poly-Vinyl Chloride (PVC)		Copper Tinned	Audio Control Instrumentation	Poly-Vinyl Chloride (PVC)			Chrome	Drain Wire	22 AWG	8	80 °C	-20 ░C	Foil	0.813 mm	0.032 in	UL Style 2464	100 ft	30.5 m
Belden Inc. 9305 060U1000	Aluminum	100 %	Solid	6.73 mm	0.265 in	Multi-Pair	Poly-Vinyl Chloride (PVC)	300 VDC	Copper Tinned	Audio Control Instrumentation	Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	Chrome	Drain Wire	22 AWG	8	80 °C	-20 ░C	Foil	0.813 mm	0.032 in
Belden Inc. 9305 060U500	Aluminum	100 %	Solid	6.73 mm	0.265 in	Multi-Pair	Poly-Vinyl Chloride (PVC)	300 VDC	Copper Tinned	Audio Control Instrumentation	Poly-Vinyl Chloride (PVC)	152.4 m	500 ft	Chrome	Drain Wire	22 AWG	8	80 °C	-20 ░C	Foil	0.813 mm	0.032 in
Belden Inc. 9305 060500	Aluminum	100 %	Solid	6.73 mm	0.265 in	Multi-Pair	Poly-Vinyl Chloride (PVC)	300 VDC	Copper Tinned	Audio Control Instrumentation	Poly-Vinyl Chloride (PVC)	152.4 m	500 ft	Chrome	Drain Wire	22 AWG	8	80 °C	-20 ░C	Foil	0.813 mm	0.032 in
