414-87 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 72POS 0.1 GOLD SMD
| Part | Insulation Material | Contact Shape | Contact Material | Contact Finish - Post | Material Flammability Rating | Pitch - Mating | Pitch - Mating | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Termination | Insulation Height | Insulation Height | Insulation Color | Current Rating (Amps) | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Connector Type | Fastening Type | Contact Finish - Mating | Number of Positions Loaded | Contact Type | Number of Rows [custom] | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 72 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 24 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 30 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 44 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 62 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 16 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 4 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 4 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 38 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Tin | UL94 V-0 | 0.1 " | 2.54 mm | 54 | -55 C | 125 °C | Surface Mount | Solder | 0.165 in | 4.2 mm | Black | 3 A | 0.1 in | 2.54 mm | Socket | Push-Pull | Gold | All | Female Socket | 2 | Flash |
