3SB2207 Series
Manufacturer: Siemens
Beta
⌘K
PUSHBUTTON,MOMENTARY,FLUSH,RED,I
| Part | Mechanical Life | Circuit | Termination Style | Color - Actuator/Cap | Voltage Rating - AC | Current Rating (Amps) | Type | Operating Temperature [Min] | Operating Temperature [Max] | Actuator Type | Ingress Protection | Switch Function | Mounting Type | Panel Cutout Dimensions [diameter] | Voltage Rating - DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Siemens | 3000000 Cycles | SPST-NC | Quick Connect | Red | 110 V | 6 A 10 A | Illuminated Standard | -25 °C | 60 °C | Button Flush Round | IP65 - Dust Tight Water Resistant | On-Mom | Panel Mount Front | 16 mm | 24 V |
 Siemens | 3000000 Cycles | SPST-NC | Quick Connect | Red | 110 V | 6 A 10 A | Illuminated Standard | -25 °C | 60 °C | Button Round | IP65 - Dust Tight Water Resistant | On-Mom | Panel Mount Front | 16 mm | 24 V |
