745-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 29POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Finish | Read Out | Termination | Card Type | Contact Type | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Number of Rows | Number of Positions/Bay/Row | Gender | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Mounting Type | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Press-Fit | Non Specified - Single Edge | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 29 | 1 | 29 | Female | 30 Áin | 0.76 Ám | 0.1 " | 2.54 mm | Through Hole | Black |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Press-Fit Wire Wrap | Non Specified - Single Edge | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 29 | 1 | 29 | Female | 30 Áin | 0.76 Ám | 0.1 " | 2.54 mm | Through Hole | Black |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Press-Fit | Non Specified - Single Edge | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 29 | 1 | 29 | Female | 30 Áin | 0.76 Ám | 0.1 " | 2.54 mm | Through Hole | Black |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Press-Fit | Non Specified - Single Edge | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 29 | 1 | 29 | Female | 30 Áin | 0.76 Ám | 0.1 " | 2.54 mm | Through Hole | Black |
