842-052 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 52POS 0.100
| Part | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Contact Type | Contact Finish | Contact Material | Mounting Type | Flange Feature | Termination | Card Type | Pitch | Pitch | Termination Rows | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Color | Number of Positions | Gender | Contact Finish Thickness | Contact Finish Thickness | Material - Insulation | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Cantilever | Gold | Copper Alloy | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Single | 125 °C | -40 C | 52 | Green | 52 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | ||||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Copper Alloy | Through Hole | Flush Mount Top Opening Unthreaded | Wire Wrap | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | 125 °C | -40 C | 26 | Green | 50 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 2 | 0.156 " | 3.96 mm | 2 | ||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Cantilever | Gold | Copper Alloy | Through Hole | Flush Mount Top Opening Unthreaded | Solder | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Single | 125 °C | -40 C | 52 | Green | 52 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Cantilever | Gold | Copper Alloy | Through Hole | Flush Mount Top Opening Unthreaded | Solder | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Single | 125 °C | -40 C | 52 | Green | 52 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Copper Alloy | Through Hole | Solder | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | 125 °C | -40 C | 26 | Green | 50 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 2 | 2 | |||||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Cantilever | Gold | Copper Alloy | Through Hole | Flush Mount Top Opening Unthreaded | Solder | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Single | 125 °C | -40 C | 52 | Green | 52 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Cantilever | Gold | Copper Alloy | Through Hole | Wire Wrap | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Single | 125 °C | -40 C | 52 | Green | 52 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | |||||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Copper Alloy | Through Hole | Floating Bobbin Flush Mount | Wire Wrap | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | 125 °C | -40 C | 26 | Green | 50 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 2 | 0.116 " | 2.95 mm | 2 | ||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Cantilever | Gold | Copper Alloy | Through Hole | Floating Bobbin Flush Mount | Solder | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Single | 125 °C | -40 C | 52 | Green | 52 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 0.116 " | 2.95 mm | ||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Copper Alloy | Right Angle Through Hole | Flush Mount M3 Threaded Insert Top Opening | Solder | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | 125 °C | -40 C | 26 | Green | 50 | Female | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 2 | 2 |
