HSE18L Series

Catalog

SENSOR THROUGH-BEAM 60M LO/DO

Part	Sensing Method	Voltage - Supply [Min]	Voltage - Supply [Max]	Response Time	Operating Temperature [Max]	Operating Temperature [Min]	Sensing Distance	Sensing Distance	Adjustment Type	Connection Method	Light Source	Ingress Protection	Output Configuration	Sensing Distance [Max]	Sensing Distance [Min]	Sensing Distance [Min]	Sensing Distance [Max]	Cable Length	Cable Length
SICK, Inc. HSE18L-F4A5BG	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 °C	60 m	2362.205 "	Adjustable Potentiometer	Connector M12	Red Laser Diode (655nm)	IP67
SICK, Inc. 1074776	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 ░C				Connector M12 4POS	Red Laser Diode (655nm)	IP67 IP69K	PNP - Dark-ON/Light-ON - Selectable	5000 cm	0 m	0 "	1968.504 "
SICK, Inc. 1071030	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 °C	60 m	2362.205 "		Connector M8	Red Laser Diode (655nm)	IP67	PNP
SICK, Inc. 1074778	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 ░C				Connector M12 4POS	Red Laser Diode (655nm)	IP67 IP69K		5000 cm	0 m	0 "	1968.504 "
SICK, Inc. 1084296	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 °C	60 m	2362.205 "		Cable	Red Laser Diode (655nm)	IP67	NPN PNP					78.74 "	2 m
SICK, Inc. HSE18L-B4A5AA	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 °C	60 m	2362.205 "		Connector M12	Red Laser Diode (655nm)	IP67	NPN PNP
SICK, Inc. 1083140	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 °C	60 m	2362.205 "		Connector M12	Red Laser Diode (655nm)	IP67	NPN
SICK, Inc. 1079186	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 °C	60 m	2362.205 "	Adjustable Potentiometer	Cable with Connector	Red Laser Diode (655nm)	IP67	PNP					5.906 in	150 mm
SICK, Inc. 1080173	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 °C	60 m	2362.205 "		Connector M12	Red Laser Diode (655nm)	IP67	NPN PNP
SICK, Inc. 1078565	Through-Beam	10 VDC	30 VDC	500 µs	55 °C	-30 °C	60 m	2362.205 "	Adjustable Potentiometer	Connector M12	Red Laser Diode (655nm)	IP67	PNP
