090130 Series

Manufacturer: Molex

Catalog

CONN HEADER VERT 32POS 2.54MM

Part	Contact Finish - Post	Fastening Type	Contact Type	Insulation Material	Contact Shape	Contact Material	Number of Rows	Contact Length - Mating	Contact Length - Mating	Termination	Insulation Height	Insulation Height	Style	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Color	Applications	Material Flammability Rating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Length - Post	Contact Length - Post	Connector Type	Number of Positions Loaded	Shrouding	Mounting Type	Pitch - Mating	Pitch - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish Thickness - Mating	Number of Positions	Contact Finish - Mating	Number of Positions Loaded	Number of Positions
Molex 0901301132	Tin	Latch Holder	Male Pin	Polyester Glass Filled	Square	Brass	2	0.266 in	6.75 mm	Solder	0.429 in	10.9 mm	Board to Cable/Wire	118.1 µin	3 µm	Black	Automotive General Purpose	UL94 V-0	2.54 mm	0.1 in	0.114 in	2.9 mm	Header	All	Shrouded - 4 Wall	Through Hole	0.1 in	2.54 mm
Molex 0901303306	Tin	Latch Holder	Male Pin	Polyester Glass Filled	Square	Brass	2	0.266 in	6.75 mm	Solder	0.384 in	9.75 mm	Board to Cable/Wire	0.76 Ám		Black	Automotive General Purpose	UL94 V-0	2.54 mm	0.1 in	0.114 in	2.9 mm	Header	All	Shrouded - 4 Wall	Through Hole Right Angle	0.1 in	2.54 mm	3 µm	118.1 µin	30 Áin	6	Gold
Molex 0901303144
Molex 0901303424
Molex 0901308212	Tin	Latch Holder	Male Pin	Polyester Glass Filled	Square	Brass	2	0.266 in	6.75 mm	Solder	0.429 in	10.9 mm	Board to Cable/Wire	0.38 µm		Black	Automotive General Purpose	UL94 V-0	2.54 mm	0.1 in	0.114 in	2.9 mm	Header		Shrouded - 4 Wall	Through Hole	0.1 in	2.54 mm	3 µm	118.1 µin	15 µin	12	Gold	11
Molex 0901303128	Tin	Latch Holder	Male Pin	Polyester Glass Filled	Square	Brass	2	0.266 in	6.75 mm	Solder	0.384 in	9.75 mm	Board to Cable/Wire	118.1 µin	3 µm	Black	Automotive General Purpose	UL94 V-0	2.54 mm	0.1 in	0.114 in	2.9 mm	Header	All	Shrouded - 4 Wall	Through Hole Right Angle	0.1 in	2.54 mm				28
Molex 0901303116	Tin	Latch Holder	Male Pin	Polyester Glass Filled	Square	Brass	2	0.266 in	6.75 mm	Solder	0.384 in	9.75 mm	Board to Cable/Wire	118.1 µin	3 µm	Black	Automotive General Purpose	UL94 V-0	2.54 mm	0.1 in	0.114 in	2.9 mm	Header	All	Shrouded - 4 Wall	Through Hole Right Angle	0.1 in	2.54 mm							16
Molex 0901303212	Tin	Latch Holder	Male Pin	Polyester Glass Filled	Square	Brass	2	0.266 in	6.75 mm	Solder	0.384 in	9.75 mm	Board to Cable/Wire	0.38 µm		Black	Automotive General Purpose	UL94 V-0	2.54 mm	0.1 in	0.114 in	2.9 mm	Header	All	Shrouded - 4 Wall	Through Hole Right Angle	0.1 in	2.54 mm	3 µm	118.1 µin	15 µin	12	Gold
Molex 0901301312	Tin	Latch Holder	Male Pin	Polyester Glass Filled	Square	Brass	2	0.266 in	6.75 mm	Solder	0.429 in	10.9 mm	Board to Cable/Wire	0.76 Ám		Black	Automotive General Purpose	UL94 V-0	2.54 mm	0.1 in	0.114 in	2.9 mm	Header	All	Shrouded - 4 Wall	Through Hole	0.1 in	2.54 mm	3 µm	118.1 µin	30 Áin	12	Gold
Molex 0901301208	Tin	Latch Holder	Male Pin	Polyester Glass Filled	Square	Brass	2	0.266 in	6.75 mm	Solder	0.429 in	10.9 mm	Board to Cable/Wire	0.38 µm		Black	Automotive General Purpose	UL94 V-0	2.54 mm	0.1 in	0.114 in	2.9 mm	Header	All	Shrouded - 4 Wall	Through Hole	0.1 in	2.54 mm	3 µm	118.1 µin	15 µin	8	Gold
