307-017 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 17POS 0.156
| Part | Material - Insulation | Termination Rows | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Flange Feature | Pitch | Pitch | Number of Rows | Gender | Color | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Card Type | Number of Positions/Bay/Row [custom] | Contact Type | Contact Finish | Contact Material | Read Out | Mounting Type | Features | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 1 | Female | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 17 | Semi Bellows | Gold | Copper Alloy | Single | Right Angle Through Hole | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 1 | Female | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 17 | Semi Bellows | Gold | Copper Alloy | Single | Through Hole | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Wire Wrap | Floating Bobbin Flush Mount | 3.96 mm | 0.156 in | Female | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | Semi Bellows | Gold | Copper Alloy | Dual | Right Angle Through Hole | 2 | 0.116 " | 2.95 mm | 34 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | 3.96 mm | 0.156 in | 1 | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 17 | Semi Bellows | Tin | Copper Alloy | Single | Through Hole | ||||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Wire Wrap | Floating Bobbin Flush Mount | 3.96 mm | 0.156 in | 1 | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 17 | Semi Bellows | Tin | Copper Alloy | Single | Through Hole | 0.116 " | 2.95 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | 1 | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 17 | Semi Bellows | Tin | Copper Alloy | Single | Through Hole | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Wire Wrap | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Female | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | Semi Bellows | Gold | Copper Alloy | Dual | Right Angle Through Hole | 2 | 0.156 " | 3.96 mm | 34 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder Eyelet(s) | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Female | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | Semi Bellows | Gold | Copper Alloy | Dual | Surface Mount | 2 | 0.128 " | 3.25 mm | 34 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 1 | Female | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 17 | Semi Bellows | Gold | Copper Alloy | Single | Through Hole | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | 1 | Female | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 17 | Semi Bellows | Gold | Copper Alloy | Single | Through Hole | 0.156 " | 3.96 mm |
