174-E50 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 50POS R/A SLDR
| Part | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Color | Contact Type | Contact Finish Thickness | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Backset Spacing | Backset Spacing | Features | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Connector Type | Flange Feature | Connector Style | Number of Positions | Contact Finish | Current Rating (Amps) | Termination | Material Flammability Rating | Number of Rows [custom] | Mounting Type | Shell Material, Finish | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Brass | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | White | Signal | Flash | Steel | Yellow Chromate Plated | 9.4 mm | 0.37 in | Mounting Brackets | 5 | D DD | Receptacle Female Sockets | Mating Side Standard Screws (4-40) | D-Sub | 50 | Gold | 5 A | Solder | UL94 V-0 | 3 | Panel Mount Right Angle Through Hole | ||
 NorComp Inc. | Brass | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | White | Signal | Flash | 9.4 mm | 0.37 in | 5 | D DD | Receptacle Female Sockets | Housing/Shell (Unthreaded) | D-Sub | 50 | Gold | 5 A | Solder | UL94 V-0 | 3 | Panel Mount Right Angle Through Hole | Nickel Plated Steel | ||||
 NorComp Inc. | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | White | Signal | Flash | Steel | Yellow Chromate Plated | 9.4 mm | 0.37 in | 5 | D DD | Plug Male Pins | Housing/Shell (Unthreaded) | D-Sub | 50 | Gold | 5 A | Solder | UL94 V-0 | 3 | Panel Mount Right Angle Through Hole | ||||
 NorComp Inc. | Brass | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | White | Signal | Flash | Steel | Yellow Chromate Plated | 9.4 mm | 0.37 in | Mounting Brackets | 5 | D DD | Receptacle Female Sockets | 4-40 Mating Side Female Screwlock | D-Sub | 50 | Gold | 5 A | Solder | UL94 V-0 | 3 | Panel Mount Right Angle Through Hole | ||
 NorComp Inc. | Brass | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | White | Signal | Flash | 9.4 mm | 0.37 in | Mounting Brackets | 5 | D DD | Receptacle Female Sockets | 4-40 Mating Side Female Screwlock | D-Sub | 50 | Gold | 5 A | Solder | UL94 V-0 | 3 | Panel Mount Right Angle Through Hole | Nickel Plated Steel | |||
 NorComp Inc. | Brass | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | White | Signal | Flash | 9.4 mm | 0.37 in | Board Lock Grounding Indents Mounting Brackets | 5 | D DD | Plug Male Pins | Housing/Shell | D-Sub | 50 | Gold | 5 A | Solder | UL94 V-0 | 3 | Panel Mount Right Angle Through Hole | Nickel Plated Steel | 4-40 | ||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | White | Signal | Flash | 9.4 mm | 0.37 in | Grounding Indents | 5 | D DD | Plug Male Pins | Housing/Shell (Unthreaded) | D-Sub | 50 | Gold | 5 A | Solder | UL94 V-0 | 3 | Panel Mount Right Angle Through Hole |
