RR3112L Series
Manufacturer: E-Switch
Beta
⌘K
SWITCH ROCKER SPST 16A 125V
| Part | Mechanical Life | Electrical Life | Illumination Voltage (Nominal) | Termination Style | Voltage Rating - AC | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Actuator Marking | Switch Function | Current Rating (Amps) | Color - Actuator/Cap | Actuator Type | Illumination Type, Color | Circuit | Panel Cutout Dimensions [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | 20000 Cycles | 6000 Cycles | 3 VDC | Quick Connect | 125 V | 0 °C | 65 °C | Panel Mount Snap-In | No Marking | On-Off | 16 A | Black | Round - Illuminated | LED Red | SPST | 20.2 mm |
 E-Switch | 20000 Cycles | 6000 Cycles | 12 VDC | Quick Connect | 125 V | 0 °C | 65 °C | Panel Mount Snap-In | No Marking | On-Off | 16 A | Black | Round - Illuminated | Blue LED | SPST | 20.2 mm |
E-Switch | 20000 Cycles | 6000 Cycles | 12 VDC | Quick Connect | 125 V | 0 °C | 65 °C | Panel Mount Snap-In | No Marking | On-Off | 16 A | Red | Round - Illuminated | LED Red | SPST | 20.2 mm |
E-Switch | 20000 Cycles | 6000 Cycles | 12 VDC | Quick Connect | 125 V | 0 °C | 65 °C | Panel Mount Snap-In | No Marking | On-Off | 16 A | Black | Round - Illuminated | LED Red | SPST | 20.2 mm |
