807-008 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FML 8POS 0.156 TIN
| Part | Material - Insulation | Termination Rows | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Gender | Number of Positions/Bay/Row | Color | Contact Type | Pitch | Pitch | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Card Type | Number of Rows | Termination | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Right Angle Through Hole | Single | 125 °C | -40 C | Tin | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 1 | Solder | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | Single | 125 °C | -40 C | Tin | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 1 | Solder | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Right Angle Through Hole | Dual | 125 °C | -40 C | Tin | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 16 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Solder | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | Single | 125 °C | -40 C | Gold | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 1 | Solder | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | Right Angle Through Hole | Single | 125 °C | -40 C | Gold | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 1 | Solder | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Right Angle Through Hole | Dual | 125 °C | -40 C | Tin | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 16 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Solder | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Right Angle Through Hole | Single | 125 °C | -40 C | Gold | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 1 | Solder | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Single | 125 °C | -40 C | Tin | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 1 | Wire Wrap | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Right Angle Through Hole | Single | 125 °C | -40 C | Gold | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 1 | Solder | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Right Angle Through Hole | Dual | 125 °C | -40 C | Tin | Female | 8 | Green | Semi Bellows | 3.96 mm | 0.156 in | 16 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Solder | 2 |
