337-062 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 62POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Pitch | Pitch | Number of Rows [custom] | Flange Feature | Number of Positions/Bay/Row [custom] | Number of Positions | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Gender | Features | Contact Material | Color | Termination | Card Type | Contact Finish | Read Out | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 4-40 Threaded Insert Top Mount Opening | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Card Guides | Copper Alloy | Green | Wire Wrap | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | Green | Wire Wrap | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Right Angle Through Hole | -40 C | 105 ░C | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 4-40 Threaded Insert Top Mount Opening | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Card Guides | Copper Alloy | Green | Wire Wrap | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Right Angle Through Hole | -40 C | 105 ░C | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Card Extender | Copper Alloy | Green | Solder Eyelet(s) | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | -40 C | 105 ░C | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Card Extender | Copper Alloy | Green | Solder | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | -40 C | 105 ░C | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 4-40 Threaded Insert Top Mount Opening | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Card Guides | Copper Alloy | Green | Solder | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Card Extender | Copper Alloy | Green | Solder | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | -40 C | 105 ░C | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 4-40 Threaded Insert Top Mount Opening | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | Green | Wire Wrap | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 4-40 Threaded Insert Top Mount Opening | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Card Extender Card Guides | Copper Alloy | Green | Solder | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | -40 C | 105 ░C | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 2 | 4-40 Threaded Insert Top Mount Opening | 31 | 62 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Card Extender Card Guides | Copper Alloy | Green | Solder Eyelet(s) | Non Specified - Dual Edge | Gold | Dual | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | -40 C | 105 ░C |
