29663 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE SPST 50MA 24V
| Part | Coil Resistance | Coil Type | Coil Current | Contact Form | Termination Style | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | Operate Time | Contact Rating (Current) | Coil Voltage | Switching Voltage [Max] | Features | Mounting Type | Relay Type | Contact Material | Release Time | Coil Voltage | Coil Voltage | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 2.67 kOhms | Non Latching | 9 mA | SPST-NO (1 Form A) | Screw Terminal | -25 °C | 60 °C | cULus DNV EAC UL | 5 ms | 50 mA | 24 VDC | 30 VAC 36 VDC | Lighted Indicator Socket Included | DIN Rail | General Purpose | Gold (Au) Silver Tin Oxide (AgSnO) | 8 ms | |||
 Phoenix Contact | 34.29 kOhms | Non Latching | 3.5 mA | SPST-NO (1 Form A) | Screw Terminal | -25 °C | 55 °C | cULus DNV EAC UL | 6 ms | 50 mA | 30 VAC 36 VDC | Lighted Indicator Socket Included | DIN Rail | General Purpose | Gold (Au) Silver Tin Oxide (AgSnO) | 15 ms | 120VAC/DC | |||
 Phoenix Contact | 71.88 kOhms | Non Latching | 3.2 mA | SPST-NO (1 Form A) | Screw Terminal | -25 °C | 55 °C | cULus DNV EAC UL | 7 ms | 50 mA | 30 VAC 36 VDC | Lighted Indicator Socket Included | DIN Rail | General Purpose | Gold (Au) Silver Tin Oxide (AgSnO) | 15 ms | 230 VDC | 230 VAC |
