M55-700 Series

Catalog

CONN HEADER SMD 50POS 1.27MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Mated Stacking Heights	Applications	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Post	Contact Type	Mounting Type	Pitch - Mating	Pitch - Mating	Contact Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Insulation Material	Features	Fastening Type	Contact Length - Mating	Contact Length - Mating	Shrouding	Number of Rows [custom]	Number of Positions Loaded	Current Rating (Amps)	Insulation Color	Contact Shape	Insulation Height	Insulation Height	Material Flammability Rating	Row Spacing - Mating	Row Spacing - Mating	Connector Type	Contact Finish - Mating
Harwin Inc. M55-7005042R	2.54 µm	100 µin	8 mm 10.8 mm 15.4 mm	Automotive General Purpose Industrial	50	-55 C	125 °C	Tin	Male Pin	Surface Mount	1.27 mm	0.05 in	Phosphor Bronze	0.025 µm	1 µin	Solder	Liquid Crystal Polymer (LCP)	Board Guide Pick and Place Solder Retention	Latch Lock	4 mm	0.157 in	Shrouded - 4 Wall	2	All	1.2 A	Black	Rectangular	0.266 in	6.76 mm	UL94 V-0	0.05 in	1.27 mm	Header	Gold
Harwin Inc. M55-7008042R	2.54 µm	100 µin	8 mm 10.8 mm 15.4 mm	Automotive General Purpose Industrial	80	-55 C	125 °C	Tin	Male Pin	Surface Mount	1.27 mm	0.05 in	Phosphor Bronze	0.025 µm	1 µin	Solder	Liquid Crystal Polymer (LCP)	Board Guide Pick and Place Solder Retention	Latch Lock	4 mm	0.157 in	Shrouded - 4 Wall	2	All	1.2 A	Black	Rectangular	0.266 in	6.76 mm	UL94 V-0	0.05 in	1.27 mm	Header	Gold
Harwin Inc. M55-7001642R	2.54 µm	100 µin	8 mm 10.8 mm 15.4 mm	Automotive General Purpose Industrial	16	-55 C	125 °C	Tin	Male Pin	Surface Mount	1.27 mm	0.05 in	Phosphor Bronze	0.025 µm	1 µin	Solder	Liquid Crystal Polymer (LCP)	Board Guide Pick and Place Solder Retention	Latch Lock	4 mm	0.157 in	Shrouded - 4 Wall	2	All	1.2 A	Black	Rectangular	0.266 in	6.76 mm	UL94 V-0	0.05 in	1.27 mm	Header	Gold
Harwin Inc. M55-7002042R	2.54 µm	100 µin	8 mm 10.8 mm 15.4 mm	Automotive General Purpose Industrial	20	-55 C	125 °C	Tin	Male Pin	Surface Mount	1.27 mm	0.05 in	Phosphor Bronze	0.025 µm	1 µin	Solder	Liquid Crystal Polymer (LCP)	Board Guide Pick and Place Solder Retention	Latch Lock	4 mm	0.157 in	Shrouded - 4 Wall	2	All	1.2 A	Black	Rectangular	0.266 in	6.76 mm	UL94 V-0	0.05 in	1.27 mm	Header	Gold
Harwin Inc. M55-7002642R	2.54 µm	100 µin	8 mm 10.8 mm 15.4 mm	Automotive General Purpose Industrial	26	-55 C	125 °C	Tin	Male Pin	Surface Mount	1.27 mm	0.05 in	Phosphor Bronze	0.025 µm	1 µin	Solder	Liquid Crystal Polymer (LCP)	Board Guide Pick and Place Solder Retention	Latch Lock	4 mm	0.157 in	Shrouded - 4 Wall	2	All	1.2 A	Black	Rectangular	0.266 in	6.76 mm	UL94 V-0	0.05 in	1.27 mm	Header	Gold
