S08B-PUD Series
Manufacturer: JST Sales America Inc.
Beta
⌘K
CONN HEADER R/A 8POS 2MM
| Part | Contact Type | Voltage Rating | Insulation Color | Contact Material | Fastening Type | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions Loaded | Shrouding | Contact Shape | Material Flammability Rating | Style | Number of Positions | Row Spacing - Mating | Row Spacing - Mating | Pitch - Mating | Pitch - Mating | Contact Length - Post | Contact Length - Post | Number of Rows [custom] | Features | Insulation Height | Insulation Height | Termination | Current Rating (Amps) | Connector Type | Insulation Material | Contact Finish - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 JST Sales America Inc. | Male Pin | 250 V | Natural | Copper Alloy | Latch Holder | Right Angle Through Hole | 85 °C | -25 °C | All | Shrouded - 4 Wall | Square | UL94 V-0 | Board to Cable/Wire | 8 | 2 mm | 0.079 in | 0.079 " | 2 mm | 0.118 in | 3 mm | 2 | Board Guide | 0.335 " | 8.51 mm | Solder | 3 A | Header | Glass Filled Nylon 6/6 Polyamide (PA66) | Tin |
