MI-J00 Series

Catalog

ISOLATED DC/DC CONVERTERS - THROUGH HOLE MIJ70IA 165V/5V 10W

Part	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Voltage - Input (Min) [Min]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Current - Output (Max) [Max]	Number of Outputs	Package / Case	Efficiency	Mounting Type	Voltage - Isolation	Features	Voltage - Input (Max) [Max]	Power (Watts)	Type	Voltage - Output 1	Current - Output (Max)	Voltage - Output 1 [custom]
Vicor Corporation MI-J70-IA	85 °C	-40 C	ITE (Commercial)	100 VDC	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	2 A	1	9-DIP Module	90 %	Through Hole	3000 V	OCP OTP OVP Remote On/Off	310 V	10 W	Isolated Module	5 V
Vicor Corporation MI-J2M-IY	85 °C	-40 C	ITE (Commercial)	18 V	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm		1	9-DIP Module	90 %	Through Hole	3000 V	OCP OTP OVP Remote On/Off	50 V	50 W	Isolated Module	10 V	5 A
Vicor Corporation MI-J6L-IA	85 °C	-40 C	ITE (Commercial)	125 V	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	357 mA	1	9-DIP Module	90 %	Through Hole	3000 V	OCP OTP OVP Remote On/Off	400 VDC	10 W	Isolated Module	28 V
Vicor Corporation MI-J71-IY	85 °C	-40 C	ITE (Commercial)	100 VDC	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	4.16 A	1	9-DIP Module	90 %	Through Hole	3000 V	OCP OTP OVP Remote On/Off	310 V	50 W	Isolated Module	12 V
Vicor Corporation MI-J2X-IY	85 °C	-40 C	ITE (Commercial)	18 V	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	9.6 A	1	9-DIP Module	90 %	Through Hole	3000 V	OCP OTP OVP Remote On/Off	50 V	50 W	Isolated Module	5.2 V
Vicor Corporation MI-J62-MY	85 °C	-55 C	ITE (Commercial)	125 V	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	3.33 A	1	9-DIP Module	90 %	Through Hole	3000 V	OCP OTP OVP Remote On/Off	400 VDC	50 W	Isolated Module	15 V
Vicor Corporation MI-J23-MY-B1
Vicor Corporation MI-J2J-MY	85 °C	-55 C	ITE (Commercial)	18 V	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	1.4 A	1	9-DIP Module	90 %	Through Hole	3000 V	OCP OTP OVP Remote On/Off	50 V	50 W	Isolated Module			36 V
Vicor Corporation MI-J6Y-MY	85 °C	-55 C	ITE (Commercial)	125 V	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	10 A	1	9-DIP Module	90 %	Through Hole	3000 V	OCP OTP OVP Remote On/Off	400 VDC	50 W	Isolated Module	3.3 V
Vicor Corporation MI-J73-MA	85 °C	-55 C	ITE (Commercial)	100 VDC	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm		1	9-DIP Module	90 %	Through Hole	3000 V	OCP OTP OVP Remote On/Off	310 V	10 W	Isolated Module	24 V
