1602 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN TERM PIN 13.5-17AWG CRIMP
| Part | Material - Insulation | Insulation Diameter [Min] | Insulation Diameter [Max] | Insulation Diameter [Max] | Insulation Diameter [Min] | Length - Overall [x] | Length - Overall [x] | Contact Material | Color | Termination | Diameter - Barrel [diameter] | Diameter - Barrel [diameter] | Wire Gauge [Max] | Wire Gauge [Min] | Insulation | Length - Barrel | Length - Barrel | Contact Finish | Terminal Type | Features | Thickness | Thickness | Stud/Tab Size | Mounting Type | Width - Outer Edges | Width - Outer Edges |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Poly-Vinyl Chloride (PVC) | 0.118 in | 4.9 mm | 0.193 in | 3 mm | 19.51 mm | 0.768 in | Copper | Blue | Crimp | 4 mm | 0.157 " | 17 AWG | 14 AWG | Non-Mating End Insulated | 0.343 in | 8.7 mm | Tin | Male Pin (Plug) | |||||||
 TE Connectivity AMP Connectors | Poly-Vinyl Chloride (PVC) | 0.15 in | 6.4 mm | 0.252 in | 3.81 mm | 34.1 mm | 1.343 in | Copper | Yellow | Crimp | 12 AWG | 10 AWG | Insulated | Tin | Circular | Serrated Termination | 0.039 in | 0.99 mm | 0.25 Stud | Free Hanging (In-Line) | 13.49 mm | 0.531 in |
