292231 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER SMD 6POS 1.5MM
| Part | Number of Positions Loaded | Contact Length - Mating [custom] | Contact Length - Mating [custom] | Insulation Material | Contact Material | Fastening Type | Insulation Color | Style | Shrouding | Material Flammability Rating | Connector Type | Number of Rows | Contact Finish - Post | Mounting Type | Termination | Contact Shape | Current Rating (Amps) | Applications | Contact Type | Voltage Rating | Insulation Height | Insulation Height [z] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | All | 2.4 mm | 0.094 in | Glass Filled Nylon Polyamide (PA) | Brass | Detent Lock | Beige | Board to Cable/Wire | Shrouded - 4 Wall | UL94 V-0 | Header | 1 | Tin | Surface Mount | Solder | Square | Varies by Wire Gauge | General Purpose | Male Pin | 50 VAC | 6.91 mm | 0.272 " | -30 ░C | 105 ░C | 6 |
 TE Connectivity Raychem Cable Protection | All | 2.4 mm | 0.094 in | Glass Filled Nylon Polyamide (PA) | Brass | Detent Lock | Beige | Board to Cable/Wire | Shrouded - 4 Wall | UL94 V-0 | Header | 1 | Tin | Surface Mount | Solder | Square | Varies by Wire Gauge | General Purpose | Male Pin | 50 VAC | 6.91 mm | 0.272 " | -30 ░C | 105 ░C | 4 |
TE Connectivity Raychem Cable Protection | All | 2.4 mm | 0.094 in | Glass Filled Nylon Polyamide (PA) | Brass | Detent Lock | Beige | Board to Cable/Wire | Shrouded - 4 Wall | UL94 V-0 | Header | 1 | Tin | Surface Mount | Solder | Square | Varies by Wire Gauge | General Purpose | Male Pin | 50 VAC | 6.91 mm | 0.272 " | -30 ░C | 105 ░C | 8 |
