Blowers & Centrifugal Fans Backward-Curved Motorized Impeller, 310mm Round, 115VAC, Ball Bearing, IP44
Blowers & Centrifugal Fans Backward-Curved Motorized Impeller, 310mm Round, 115VAC, Ball Bearing, IP44
Blowers & Centrifugal Fans Backward-Curved Motorized Impeller, 310mm Round, 115VAC, Ball Bearing, IP44
| Part | Material - Blade [custom] | Weight | Weight | Size / Dimension [diameter] | Width [x] | Fan Type | Noise | Voltage - Rated | RPM | Bearing Type | Air Flow | Air Flow | Termination | Power (Watts) | Features | Material - Blade | Approval Agency | Current Rating (Amps) | Ingress Protection | Operating Temperature | Operating Temperature | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Weight [custom] | Weight [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | Aluminum | 9.7 lbs | 4.4 kg | 318 mm | 154 mm | Motorized Impellers | 65 dB | 230 VAC | 1700 RPM | Ball | 1430 CFM | 40.04 m³/min | 2 Wire Leads | 240 Watts | Capacitor | ||||||||||||
 ebm-papst Inc. | 8 lbs | 3.6 kg | 318 mm | 154 mm | Motorized Impellers | 68 dB | 115 VAC | Ball | 1265 CFM | 35.42 m³/min | 2 Wire Leads | 155 W | Capacitor | Polyamide (PA) Nylon | CCC CSA UL | ||||||||||||
 ebm-papst Inc. | 318 mm | 154 mm | Motorized Impellers | 230 VAC | 1600 RPM | Ball | 2 Wire Leads | 140 W | Capacitor Thermal Overload Protector (TOP) | Polyamide (PA66) Nylon 6/6 | 0.62 A | IP44 | 131 °F | 55 °C | |||||||||||||
ebm-papst Inc. | 318 mm | 123 mm | Motorized Impellers | 277 VAC | Ball | Capacitor | |||||||||||||||||||||
ebm-papst Inc. | Aluminum | 318 mm | 154 mm | Motorized Impellers | 277 VAC | 1670 RPM | Ball | 4 Wire Leads with Splice Terminals | 210 W | Capacitor Thermal Overload Protector (TOP) | CE CSA UL | 770 mA | IP44 | 60 °C | 60 °C | ||||||||||||
 ebm-papst Inc. | Aluminum | 9.7 lbs | 4.4 kg | 318 mm | 154 mm | Motorized Impellers | 65 dB | 115 VAC | 1700 RPM | Ball | 1430 CFM | 40.04 m³/min | 2 Wire Leads | 225 W | Capacitor | ||||||||||||
 ebm-papst Inc. | Aluminum | 318 mm | 123 mm | Motorized Impellers | 277 VAC | 1730 RPM | Ball | 1177 CFM | 32.96 m³/min | 4 Wire Leads with Splice Terminals | 165 W | Capacitor Thermal Overload Protector (TOP) | CSA UL | 0.61 A | IP44 | 50 °C | -25 °C | -25 °C | 50 °C | ||||||||
ebm-papst Inc. | Aluminum | 318 mm | 154 mm | Motorized Impellers | 115 VAC | 1550 RPM | Ball | 4 Wire Leads with Splice Terminals | 170 W | Capacitor Thermal Overload Protector (TOP) | CSA UL | 1.48 A | IP44 | 50 °C | -25 °C | -25 °C | 50 °C | ||||||||||
ebm-papst Inc. | Aluminum | 318 mm | 3 Phase Motorized Impellers | 115 VAC | 1720 RPM | Ball | 4 Wire Leads with Splice Terminals | 155 W | Capacitor Thermal Overload Protection (TOP) | CSA UL | 1.5 A | IP44 | 65 °C | -25 °C | -25 °C | 65 °C | 8.3 lbs | 3.8 kg | |||||||||
 ebm-papst Inc. | 8 lbs | 3.6 kg | 318 mm | 154 mm | Motorized Impellers | 68 dB | 230 VAC | Ball | 1265 CFM | 35.42 m³/min | 2 Wire Leads | 165 W | Capacitor | Polyamide (PA) Nylon | CCC CSA UL |
