T355 Series

Manufacturer: KEMET

Catalog

TANTALUM CAPACITORS - SOLID LEADED 35VOLTS .82UF 10%

Part	Package / Case	Capacitance	Manufacturer Size Code	Voltage - Rated	Size / Dimension [diameter]	Size / Dimension [diameter]	Mounting Type	Lead Spacing	Lead Spacing	Tolerance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Type	ESR (Equivalent Series Resistance)	Features	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
KEMET T355A824K035AT7301	Radial	0.82 µF	A	35 V	4.5 mm	0.177 "	Through Hole	3.18 mm	0.125 in	10 %	0.339 in	8.6 mm	Conformal Coated	10 Ohm	General Purpose	-55 C	125 °C
KEMET T355E106K025AS	Radial	10 µF	E	25 VDC	5.5 mm	0.217 in	Through Hole	3.18 mm	0.125 in	10 %	0.4 in	10.16 mm	Conformal Coated		General Purpose	-55 C	125 °C
KEMET T355G686M006AS	Disc Radial	68 µF	T355G	6 VDC	6.3 mm	0.248 "	Through Hole	3.18 mm	0.125 in	20 %	0.449 in		Conformal Coated	1.8 Ohm	General Purpose	-55 C	125 °C	11.4 mm
KEMET T355E106M025AS7301	Disc Radial	10 µF	T355E	25 VDC	5.5 mm	0.217 in	Through Hole	3.18 mm	0.125 in	20 %			Conformal Coated	2.5 Ohm	General Purpose	-55 C	125 °C	10.2 mm	0.402 in
KEMET T355G396K010AT	Disc Radial	39 µF	T355G	10 V	6.3 mm	0.248 "	Through Hole	3.18 mm	0.125 in	10 %	0.449 in		Conformal Coated		General Purpose	-55 C	125 °C	11.4 mm
KEMET T355A224K050AT7301	Disc Radial	0.22 µF	T355A	50 VDC	4.5 mm	0.177 "	Through Hole	3.18 mm	0.125 in	10 %	0.339 in	8.6 mm	Conformal Coated	17 Ohm	General Purpose	-55 C	125 °C
KEMET T355E475M035AT	Disc Radial	4.7 µF	T355E	35 V	5.5 mm	0.217 in	Through Hole	3.18 mm	0.125 in	20 %			Conformal Coated	3 Ohm	General Purpose	-55 C	125 °C	10.2 mm	0.402 in
KEMET T355B225K025AT7301	Disc Radial	2.2 µF	T355B	25 VDC	4.5 mm	0.177 "	Through Hole	3.18 mm	0.125 in	10 %	0.35 "	8.9 mm	Conformal Coated	6 Ohm	General Purpose	-55 C	125 °C
KEMET T355A334K035AT	Radial	0.33 µF	A	35 V	4.45 mm	0.175 in	Through Hole	3.18 mm	0.125 in	10 %			Conformal Coated	15 Ohms	General Purpose	-55 C	125 °C	8.64 mm	0.34 in
KEMET T355A105K035AT	Radial	1 µF	A	35 V	4.5 mm	0.177 "	Through Hole	3.18 mm	0.125 in	10 %	0.339 in	8.6 mm	Conformal Coated	8 Ohm	General Purpose	-55 C	125 °C
