253G Series
Manufacturer: Dart Controls
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
1/8 THRU 2.0HP DUAL VOLTAGE CHAS
| Part | Voltage - Supply | Current - Output | Voltage - Load (Max) | Voltage - Load (Min) | Number of Motors | Control / Drive Type | Voltage - Load (Other) | Type | Operating Temperature (Min) | Operating Temperature (Max) | Mounting Type | Motor Type | Wattage - Load | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Dart Controls | 240 VAC | 10 A 10.8 A | 90 V 180 V | 0 V | 1 | Brushed | 180 VDC | Board | -10 °C | 45 °C | Chassis Mount | Brushed DC | 1.5 kW | 120 V | 240 VAC |
 Dart Controls | 10 A 10.8 A | 90 V | 0 V | 1 | Brushed | 180 VDC | Module | -10 °C | 45 °C | Chassis Mount | Brushed DC | 745.7 W | 120 V | 240 VAC |
