MIAD9 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
PHOTOELECTRIC SENSOR, 6.56FT, 650NM RED LED, POLARIZED RETROREFLECTIVE, DIGITAL, 4 PIN M12 CONNECTOR
| Part | Ingress Protection | Sensing Method | Operating Temperature [Max] | Operating Temperature [Min] | Output Configuration | Adjustment Type | Light Source | Sensing Distance | Sensing Distance | Voltage - Supply [Min] | Voltage - Supply [Max] | Connection Method | Cable Length | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | 12 13 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Polarized Retroreflective | 70 °C | -40 C | Light-On/Dark-On | Adjustable Potentiometer | RED (650nm) | 2 m | 78.74 in | 5 V | 15 V | Connector | ||
 BANNER ENGINEERING | 12 13 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Convergent | 70 °C | -40 C | Light-On/Dark-On | 15-Turn Potentiometer Adjustable | RED (650nm) | 43 mm | 1.693 in | 5 V | 15 V | Cable | 78.74 " | 2 m |
 BANNER ENGINEERING | 12 13 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Diffuse | 70 °C | -40 C | Light-On/Dark-On | Adjustable Potentiometer | Infrared (880nm) | 380 mm | 14.961 in | 5 V | 15 V | Connector | ||
 BANNER ENGINEERING | 12 13 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Fiber Optic | 70 °C | -40 C | Analog | Adjustable Potentiometer | Infrared (880nm) | 5 V | 15 V | Connector | ||||
 BANNER ENGINEERING | 12 13 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Retroreflective NonPolarized | 70 °C | -40 C | Light-On/Dark-On | Adjustable Potentiometer | RED (650nm) | 5 m 196.85 in | 5 V | 15 V | Connector |
