1586862 Series
Manufacturer: TE Connectivity AMP Connectors
Catalog
20P FH PLUG VAL-U-LOK FH GW
| Part | Note | Operating Temperature [Min] | Operating Temperature [Max] | Row Spacing | Row Spacing | Number of Rows [custom] | Pitch | Pitch | Contact Termination | Fastening Type | Contact Type | Number of Positions | Color | Insulation Material | Mounting Type | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Contacts Not Included | -40 C | 105 ░C | 0.165 in | 4.2 mm | 2 | 0.165 in | 4.2 mm | Crimp | Latch Lock | Male Pin | 20 | White | Nylon Polyamide (PA) | Free Hanging (In-Line) | Plug |
 TE Connectivity AMP Connectors | Contacts Not Included | -40 C | 105 ░C | 0.165 in | 4.2 mm | 2 | 0.165 in | 4.2 mm | Crimp | Latch Lock | Male Pin | 14 | White | Nylon Polyamide (PA) | Free Hanging (In-Line) | Plug |
 TE Connectivity AMP Connectors | Contacts Not Included | -40 C | 105 ░C | 0.165 in | 4.2 mm | 2 | 0.165 in | 4.2 mm | Crimp | Latch Lock | Male Pin | 6 | White | Nylon Polyamide (PA) | Free Hanging (In-Line) | Plug |
 TE Connectivity AMP Connectors | Contacts Not Included | -40 C | 105 ░C | 0.165 in | 4.2 mm | 2 | 0.165 in | 4.2 mm | Crimp | Latch Lock | Male Pin | 24 | White | Nylon Polyamide (PA) | Free Hanging (In-Line) | Plug |
 TE Connectivity AMP Connectors | Contacts Not Included | -40 C | 105 ░C | 0.165 in | 4.2 mm | 2 | 0.165 in | 4.2 mm | Crimp | Latch Lock | Male Pin | 8 | White | Nylon Polyamide (PA) | Free Hanging (In-Line) | Plug |
 TE Connectivity AMP Connectors | Contacts Not Included | -40 C | 105 ░C | 0.165 in | 4.2 mm | 2 | 0.165 in | 4.2 mm | Crimp | Latch Lock | Male Pin | 16 | White | Nylon Polyamide (PA) | Free Hanging (In-Line) | Plug |
 TE Connectivity AMP Connectors | Contacts Not Included | -40 C | 105 ░C | 0.165 in | 4.2 mm | 2 | 0.165 in | 4.2 mm | Crimp | Latch Lock | Male Pin | 12 | White | Nylon Polyamide (PA) | Free Hanging (In-Line) | Plug |
