1776112 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
TERM BLK 2POS SIDE ENT 3.5MM PCB
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Voltage | Screw Material - Plating | Number of Levels | Mounting Type | Mating Orientation | Color | Clamp Material - Plating | Pitch [x] | Pitch [x] | Wire Gauge [Max] | Wire Gauge [Min] | Contact Material - Plating | Positions Per Level | Screw Thread | Current | Housing Material | Wire Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 150 V | Copper Alloy - Nickel Plated | 1 | Through Hole | Horizontal with Board | Black | Copper Alloy - Nickel Plated | 3.5 mm | 0.138 in | 28 AWG | 16 AWG | Copper Alloy - Tin Plated | 2 | M2 | 12 A | Polyamide (PA) Nylon | Screw - Rising Cage Clamp |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 150 V | Copper Alloy - Nickel Plated | 1 | Through Hole | Horizontal with Board | Black | Copper Alloy - Nickel Plated | 3.5 mm | 0.138 in | 28 AWG | 16 AWG | Copper Alloy - Tin Plated | 3 | M2 | 12 A | Polyamide (PA) Nylon | Screw - Rising Cage Clamp |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 150 V | Copper Alloy - Nickel Plated | 1 | Through Hole | Horizontal with Board | Black | Copper Alloy - Nickel Plated | 3.5 mm | 0.138 in | 28 AWG | 16 AWG | Copper Alloy - Tin Plated | 3 | M2 | 12 A | Polyamide (PA) Nylon | Screw - Rising Cage Clamp |
TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 150 V | Copper Alloy - Nickel Plated | 1 | Through Hole | Horizontal with Board | Black | Copper Alloy - Nickel Plated | 3.5 mm | 0.138 in | 28 AWG | 16 AWG | Copper Alloy - Tin Plated | 4 | M2 | 12 A | Polyamide (PA) Nylon | Screw - Rising Cage Clamp |
