44BXFP Series

Manufacturer: KEMET

Catalog

CAP FILM 0.47UF 5% 2.4KVDC RAD

Part	Dielectric Material	Operating Temperature [Max]	Operating Temperature [Min]	ESR (Equivalent Series Resistance)	Package / Case	Tolerance	Capacitance	Lead Spacing	Lead Spacing	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Mounting Type	Voltage Rating - DC	Voltage Rating - DC	Size / Dimension [diameter]	Size / Dimension [diameter]	Termination	Voltage Rating - AC	Voltage Rating - AC	Applications	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET C44BXFP3470ZA0J	Polypropylene (PP) Metallized	85 °C	-40 C	2.5 mOhms	Can Radial	5 %	0.47 µF	22.3 mm	0.878 in	4.213 in	107 mm	Chassis Stud Mount	2400 V	2.4 kV	45 mm	1.772 "	Threaded Male	1 kV	1 kV	Snubber
KEMET C44BXFP3220ZC0J	Polypropylene (PP) Metallized	85 °C	-40 C	2.5 mOhms	Can Radial	5 %	0.22 µF	22.3 mm	0.878 in			Chassis Stud Mount	2400 V	2.4 kV	45 mm	1.772 "	Threaded Male	1 kV	1 kV	Snubber	3.15 "	80 mm
