396-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 7POS 0.125
| Part | Material - Insulation | Termination Rows | Mounting Type | Pitch | Pitch | Color | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Gender | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Contact Material | Contact Finish | Read Out | Termination | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Positions | Flange Feature | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Wire Wrap | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Right Angle Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Solder Wire Wrap | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Right Angle Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Solder Wire Wrap | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Right Angle Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Solder Wire Wrap | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | 3.18 mm | 0.125 in | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 1 | -40 C | 105 ░C | Cantilever | Copper Alloy | Gold | Single | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | Flush Mount M3 Threaded Insert Top Opening |
