LV8804 Series

Catalog

IC MOTOR DRIVER 6V-15V 20SSOP

Part	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Motor Type - AC, DC	Function	Interface	Technology	Mounting Type	Voltage - Load [Max]	Voltage - Load [Min]	Current - Output	Output Configuration	Package / Case	Package / Case	Package / Case	Supplier Device Package	Voltage - Supply [Min]	Voltage - Supply [Max]
ON Semiconductor LV8804FV-MPB-H	General Purpose	95 °C	-30 °C	Brushless DC (BLDC)	Driver - Fully Integrated Control and Power Stage	On/Off	Bi-CMOS	Surface Mount	15 V	6 V	1.2 A	Half Bridge (3)	0.173 in	4.4 mm	20-LFSOP	20-SSOPJ	6 V	15 V
ON Semiconductor LV8804V-TLM-H	Fan Motor Driver	95 °C	-30 °C	Brushless DC (BLDC)	Driver - Fully Integrated Control and Power Stage	PWM	Bi-CMOS	Surface Mount	15 V	6 V	1.2 A	Half Bridge (3)				36-SSOPJ	6 V	15 V
ON Semiconductor LV8804V-MPB-H	Fan Motor Driver	95 °C	-30 °C	Brushless DC (BLDC)	Driver - Fully Integrated Control and Power Stage	PWM	Bi-CMOS	Surface Mount	15 V	6 V	1.2 A	Half Bridge (3)				36-SSOPJ	6 V	15 V
ON Semiconductor LV8804FV-TLM-H	General Purpose	95 °C	-30 °C	Brushless DC (BLDC)	Driver - Fully Integrated Control and Power Stage	On/Off	Bi-CMOS	Surface Mount	15 V	6 V	1.2 A	Half Bridge (3)	0.173 in	4.4 mm	20-LFSOP	20-SSOPJ	6 V	15 V
