307-038 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 76POS 0.156
| Part | Material - Insulation | Termination Rows | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Color | Termination | Mounting Type | Gender | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Number of Positions/Bay/Row [custom] | Number of Rows [custom] | Pitch | Pitch | Contact Finish | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Features | Termination Rows [custom] | Number of Positions/Bay/Row |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Green | Solder | Right Angle Through Hole | Female | Semi Bellows | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 38 | 2 | 3.96 mm | 0.156 in | Gold | 76 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Green | Wire Wrap | Through Hole | Female | Semi Bellows | -40 C | 105 ░C | Non Specified - Single Edge | 38 | 3.96 mm | 0.156 in | Tin | 38 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Card Guides | |||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Copper Alloy | Green | Solder Eyelet(s) | Through Hole | Female | Semi Bellows | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Single Edge | 38 | 3.96 mm | 0.156 in | Gold | 38 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | Copper Alloy | Green | Solder | Right Angle Through Hole | Female | Semi Bellows | -40 C | 105 ░C | Non Specified - Dual Edge | 38 | 2 | 3.96 mm | 0.156 in | Tin | 76 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Single | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | Green | Wire Wrap | Through Hole | Female | Semi Bellows | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Single Edge | 38 | 3.96 mm | 0.156 in | Gold | 38 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||||||
 EDAC Inc. | Polyester Thermoplastic | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Green | Solder Wire Wrap | Right Angle Through Hole | Female | Semi Bellows | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 2 | 3.96 mm | 0.156 in | Gold | 38 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | 2 | 19 | |||||
 EDAC Inc. | Polyester Thermoplastic | Dual | Copper Alloy | Green | Solder | Board Edge Straddle Mount | Female | Semi Bellows | -40 C | 105 ░C | Non Specified - Dual Edge | 2 | 3.96 mm | 0.156 in | Tin | 38 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 19 | |||||||||
 EDAC Inc. | Polyester Thermoplastic | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Green | Solder | Board Edge Straddle Mount | Female | Semi Bellows | -40 C | 105 ░C | Non Specified - Dual Edge | 2 | 3.96 mm | 0.156 in | Tin | 38 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender Card Guides | 2 | 19 | |||||||
 EDAC Inc. | Polyester Thermoplastic | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Green | Solder | Board Edge Straddle Mount | Female | Semi Bellows | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 2 | 3.96 mm | 0.156 in | Gold | 38 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender Card Guides | 2 | 19 | |||||
 EDAC Inc. | Polyester Thermoplastic | Dual | Copper Alloy | Green | Solder | Board Edge Straddle Mount | Female | Semi Bellows | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 2 | 3.96 mm | 0.156 in | Gold | 38 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | 2 | 19 |
