25002 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 2COND 22AWG BLUE 1000'
| Part | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Features | Jacket Color | Conductor Material | Length | Length | Voltage | Cable Type | Number of Conductors | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Wire Gauge | Conductor Strand [custom] | Conductor Strand [custom] | Ratings | Jacket (Insulation) Material | Conductor Insulation | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 4.27 mm | 0.168 in | Biological Compatibility Rip Cord | Blue | Copper Tinned | 304.8 m | 1000 ft | 300 VDC | Multi-Conductor | 2 | 0.813 mm | 0.032 in | -30 ░C | 90 °C | 22 AWG | 30 AWG | 7 | ISO 10993 UL Style 20668 | Polyurethane (PU) | Poly-Vinyl Chloride (PVC) | ||
 ALPHA WIRE | 4.27 mm | 0.168 in | Biological Compatibility Rip Cord | Black | Copper Tinned | 300 VDC | Multi-Conductor | 2 | 0.813 mm | 0.032 in | -30 ░C | 90 °C | 22 AWG | 30 AWG | 7 | ISO 10993 UL Style 20668 | Polyurethane (PU) | Poly-Vinyl Chloride (PVC) | 100 ft | 30.5 m |
