8527 Series

Catalog

HOOK-UP STRND 12AWG GRY

Part	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length	Length	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Material	Cable Type	Wire Gauge	Jacket (Insulation) Material	Features	Voltage	Jacket Color	Qualification	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length [x]	Length [x]	Operating Temperature
Belden Inc. 8527 0081000	3.25 mm	0.128 in	304.8 m	1000 ft	30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	Gray	MIL-W-76C Type MW	0.021 in	0.53 mm
Belden Inc. 8527 003100	3.25 mm	0.128 in			30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	Orange	MIL-W-76C Type MW	0.021 in	0.53 mm	100 ft	30.5 m
Belden Inc. 8527 0061000	3.25 mm	0.128 in	304.8 m	1000 ft	30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	Blue	MIL-W-76C Type MW	0.021 in	0.53 mm
Belden Inc. 8527 0031000	3.25 mm	0.128 in	304.8 m	1000 ft	30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	Orange	MIL-W-76C Type MW	0.021 in	0.53 mm
Belden Inc. 8527 006100	3.25 mm	0.128 in			30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	Blue	MIL-W-76C Type MW	0.021 in	0.53 mm	100 ft	30.5 m
Belden Inc. 8527 0091000	3.25 mm	0.128 in	304.8 m	1000 ft	30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	White	MIL-W-76C Type MW	0.021 in	0.53 mm
Belden Inc. 8527 0051000	3.25 mm	0.128 in	304.8 m	1000 ft	30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	Green	MIL-W-76C Type MW	0.021 in	0.53 mm
Belden Inc. 8527 010100	3.25 mm	0.128 in			30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	Black	MIL-W-76C Type MW	0.021 in	0.53 mm	100 ft	30.5 m	80 °C
Belden Inc. 8527 005100	3.25 mm	0.128 in			30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	Green	MIL-W-76C Type MW	0.021 in	0.53 mm	100 ft	30.5 m	80 °C
Belden Inc. 8527 002100	3.25 mm	0.128 in			30 AWG	65	Copper Tinned	Hook-Up	12 AWG	Poly-Vinyl Chloride (PVC)	Chemical Resistant	1 kV	Red	MIL-W-76C Type MW	0.021 in	0.53 mm	100 ft	30.5 m	80 °C
