292173 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

CONN HEADER SMD R/A 6POS 2MM

Part	Connector Type	Contact Material	Style	Contact Finish - Post	Contact Type	Pitch - Mating [x]	Pitch - Mating [x]	Number of Positions Loaded	Shrouding	Contact Length - Mating	Contact Length - Mating	Insulation Color	Termination	Material Flammability Rating	Applications	Features	Current Rating (Amps)	Mounting Type	Number of Rows	Insulation Material	Voltage Rating	Contact Shape	Fastening Type	Insulation Height	Insulation Height	Number of Positions
TE Connectivity Raychem Cable Protection 292173-6	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Black	Solder	UL94 V-0	General Purpose	Board Guide Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in	6
TE Connectivity Raychem Cable Protection 292173-8	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Black	Solder	UL94 V-0	General Purpose	Board Guide Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in	8
TE Connectivity Raychem Cable Protection 3-292173-4	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Natural	Solder	UL94 V-0	General Purpose	Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in	4
TE Connectivity Raychem Cable Protection 292173-5	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Black	Solder	UL94 V-0	General Purpose	Board Guide Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in
TE Connectivity Raychem Cable Protection 3-292173-7	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Natural	Solder	UL94 V-0	General Purpose	Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in	7
TE Connectivity Raychem Cable Protection 3-292173-3	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Natural	Solder	UL94 V-0	General Purpose	Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in
TE Connectivity Raychem Cable Protection 292173-3	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Black	Solder	UL94 V-0	General Purpose	Board Guide Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in
TE Connectivity Raychem Cable Protection 292173-9	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Black	Solder	UL94 V-0	General Purpose	Board Guide Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in	9
TE Connectivity Raychem Cable Protection 292173-7	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Black	Solder	UL94 V-0	General Purpose	Board Guide Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in	7
TE Connectivity Raychem Cable Protection 2-292173-3	Header	Brass	Board to Cable/Wire	Tin	Male Pin	0.079 in	2 mm	All	Shrouded - 4 Wall	4.2 mm	0.165 in	Black	Solder	UL94 V-0	General Purpose	Solder Retention	Varies by Wire Gauge	Surface Mount Right Angle	1	Glass Filled Nylon 6T Polyamide (PA6T)	125 VAC	Square	Detent Lock	5.8 mm	0.228 in
