12226 Series

Catalog

JE150323127 12226-5150-00FR=26/SDR/RC/BMT/RA/THRU/SCW/7.6AU ROHS COMPLIANT: YES

Part	Contact Finish Thickness	Contact Finish Thickness	Number of Positions	Termination	Connector Style	Contact Finish	Connector Type	Mounting Type	Number of Rows [custom]	Flange Feature	Features
3M Electronic Specialty 12226-5150-00FR	30 Áin	0.76 Ám	26	Solder	Outer Shroud Contacts	Gold	Receptacle	Panel Mount Right Angle Through Hole	2	M2	Board Lock Shielded
3M Electronic Specialty 12226-5110-00FR	30 Áin	0.76 Ám	26	Solder	Outer Shroud Contacts	Gold	Receptacle	Panel Mount Right Angle Through Hole	2	Housing/Shell (M2.6)	Board Lock Shielded
3M Electronic Specialty 12226-1150-00PL	8 µin	0.203 çm	26	Solder	Outer Shroud Contacts	Gold	Receptacle	Panel Mount Through Hole	2	M2	Board Lock Shielded
3M Electronic Specialty 12226-8200-00PL	8 µin	0.203 çm	26	Solder	Outer Shroud Contacts	Gold	Receptacle	Right Angle Surface Mount	2	M2
3M Electronic Specialty 12226-8250-00PL	8 µin	0.203 çm	26	Solder	Outer Shroud Contacts	Gold	Receptacle	Right Angle Surface Mount	2	M2	Board Guide Shielded
3M Electronic Specialty 12226-1150-00FR	30 Áin	0.76 Ám	26	Solder	Outer Shroud Contacts	Gold	Receptacle	Panel Mount Through Hole	2	M2	Board Lock Shielded
3M Electronic Specialty 12226-8250-00FR	30 Áin	0.76 Ám	26	Solder	Outer Shroud Contacts	Gold	Receptacle	Right Angle Surface Mount	2	M2	Board Guide Shielded
3M Electronic Specialty 12226-1110-00FR	30 Áin	0.76 Ám	26	Solder	Outer Shroud Contacts	Gold	Receptacle	Through Hole	2		Shielded
