APA2106 Series

Catalog

LED RED CLEAR SMD R/A

Part	Supplier Device Package	Lens Color	Size / Dimension [y]	Size / Dimension [x]	Configuration	Current - Test	Viewing Angle	Height (Max) [z]	Wavelength - Peak	Package / Case	Lens Size [y]	Lens Size [x]	Lens Style	Wavelength - Dominant	Mounting Type	Color	Voltage - Forward (Vf) (Typ)	Millicandela Rating	Lens Transparency
Kingbright APA2106SURCK	SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm	645 nm	2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	630 nm	Right Angle Surface Mount	Red	1.95 V	80 mcd	Clear
Kingbright APA2106SRCPRV	2-SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm	660 nm	2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	640 nm	Right Angle Surface Mount	Red	1.85 V	30 mcd	Clear
Kingbright APA2106CGCK	SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm		2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	570 nm	Right Angle Surface Mount	Green	2.1 V	50 mcd	Clear
Kingbright APA2106VBC/D	SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm	465 nm	2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	470 nm	Right Angle Surface Mount	Blue	3.3 V	200 mcd	Clear
Kingbright APA2106SECK	SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm	610 nm	2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	601 nm	Right Angle Surface Mount		2.1 V	180 mcd	Clear
Kingbright APA2106QBC/D	SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm	460 nm	2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	465 nm	Right Angle Surface Mount	Blue	3.3 V	80 mcd	Clear
Kingbright APA2106ZGCK	SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm	515 nm	2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	525 nm	Right Angle Surface Mount	Green	3.3 V	300 mcd	Clear
Kingbright APA2106SYCK/J3-PRV	SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm	590 nm	2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	590 nm	Right Angle Surface Mount	Yellow	2 V	350 mcd	Clear
Kingbright APA2106SECK/J3-PRV	SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm	640 nm	2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	625 nm	Right Angle Surface Mount	Red	2.2 V	380 mcd	Clear
Kingbright APA2106MGC	SMD	Colorless	1 mm	2.1 mm	Standard	20 mA	120 °	0.6 mm		2-SMD No Lead	0.6 mm	1.7 mm	Rectangle with Domed Top	570 nm	Right Angle Surface Mount	Green	2.1 V	80 mcd	Clear
