621-M50 Series
Manufacturer: EDAC Inc.
Beta
⌘K
D-SUB STANDARD CONNECTORS RIGHT ANGLE D-SUB CONNECTOR
| Part | Color | Contact Material | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Flange Feature | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Connector Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Number of Positions | Material Flammability Rating | Mounting Type | Connector Style | Termination | Features | Current Rating (Amps) | Contact Finish | Backset Spacing | Backset Spacing | Shell Material, Finish | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | White | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | Housing/Shell | 4-40 | 30 Áin | 0.76 Ám | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Grounding Indents Mounting Brackets Shielded | 5 A | Gold | 7.2 mm | 0.283 in | ||
 EDAC Inc. | Green | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | Housing/Shell | 4-40 | 30 Áin | 0.76 Ám | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Grounding Indents Shielded | 5 A | Gold | 7.2 mm | 0.283 in | Nickel Plated Steel | |
 EDAC Inc. | Green | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | Housing/Shell | 4-40 | 15 µin | 0.38 µm | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Grounding Indents Shielded | 5 A | Gold | 7.2 mm | 0.283 in | Nickel Plated Steel | |
 EDAC Inc. | Green | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | Housing/Shell | 4-40 | 15 µin | 0.38 µm | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Grounding Indents Shielded | 5 A | Gold | 7.2 mm | 0.283 in | ||
 EDAC Inc. | Green | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | Housing/Shell | 4-40 | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Grounding Indents Shielded | 5 A | Gold | 7.2 mm | 0.283 in | Flash | |||
 EDAC Inc. | Black | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | Housing/Shell | 4-40 | 15 µin | 0.38 µm | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Grounding Indents Mounting Brackets Shielded | 5 A | Gold | 7.2 mm | 0.283 in | ||
 EDAC Inc. | White | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | 4-40 | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 5 A | Gold | 7.2 mm | 0.283 in | Flash | ||||
 EDAC Inc. | Green | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | Housing/Shell | 4-40 | 30 Áin | 0.76 Ám | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Grounding Indents Mounting Brackets Shielded | 5 A | Gold | 7.2 mm | 0.283 in | ||
 EDAC Inc. | Blue | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | 4-40 | 30 Áin | 0.76 Ám | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 5 A | Gold | 7.2 mm | 0.283 in | Nickel Plated Steel | ||
 EDAC Inc. | White | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | 3 | Housing/Shell | 4-40 | 15 µin | 0.38 µm | Signal | Plug Male Pins | 5 | D DD | 50 | UL94 V-0 | Board Edge Right Angle Through Hole | D-Sub | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 5 A | Gold | 7.2 mm | 0.283 in | Nickel Plated Steel |
