CH105 Series

Catalog

FASTENER, ADHESIVE BACKED CABLE CLIP, NYLON 6.6 (POLYAMIDE 6.6), GREY, 63 MM, 26.2 MM

Part	Height [z]	Height [z]	Material	Mounting Type	Adhesive	Length [x]	Length [x]	Opening Size [x]	Opening Size [z]	Opening Size [z]	Opening Size [x]	Width	Width [x]	Type Attributes	Type	Color	Screw Size	Screw Size
Panduit Corp CH105-A-C14	17.02 mm	0.67 in	Polyamide (PA66) Nylon 6/6	Adhesive	Rubber Based	2.48 "	63 mm	52.32 mm	10.03 mm	0.395 in	2.06 in	26.16 mm	1.03 in	Top Lock	Clip Wire Saddle	Gray
Panduit Corp CH105-S6-C14	15.75 mm	0.62 in	Polyamide (PA66) Nylon 6/6	Fastener		2.48 "	63 mm	52.32 mm	10.03 mm	0.395 in	2.06 in	26.16 mm	1.03 in	Top Lock	Clip Wire Saddle	Gray	M3	#6
